Granular Cell Ameloblastoma: A Case Report and Literature Review

Ameloblastoma (AB) is defined as a benign, but locally aggressive epithelial odontogenic neoplasm arising in the jaw and having close resemblance to the enamel organ epithelium [1]. Although the most common odontogenic neoplasm, it accounts for only 1% of all jaw tumors. They are slow-growing, locally invasive tumours that run a benign course in most cases [2-4]. They occur in three different clinicoradiographic situations which deserve separate consideration because of differing therapeutic considerations and prognosis [1,5-7]. These are: conventional solid or multicystic (about 86% of all cases); unicystic (about 13% of all cases); and peripheral (extraosseous; about 1% of all cases) [1,2,9,10]. It is well known that ameloblastoma can be radiologically unilocular or multilocular and that unilocular or multilocular ameloblastoma may be histologically unicystic or multicystic [10].

Sometimes, ameloblastomas present as soft tissue swellings occurring in the tooth-bearing areas of the maxilla or mandible without involvement of the underlying bone. This peripheral ameloblastoma should not be confused with intraosseous ameloblastomas that spread from within the jaw into the overlying gingiva [11]. In the past, these lesions have also been described as odontogenic gingival epithelial hamartoma [12]. For peripheral ameloblastoma simple excision will be sufficient treatment [13,14].

Granular cell ameloblastoma is a variant of ameloblastoma that histopathologically has numerous large eosinophilic granular cells. These granular cells are formed by transformation of lesional epithelial cells. Although originally considered to represent aging or degenerative changes in long standing lesions, this variant has been seen in young patients and in clinically aggressive tumors. When this granular cell change is extensive in an ameloblastoma, the designation of granular cell ameloblastoma is appropriate. The granular cells usually form the central mass of the epithelial tumor islands and cords. The periphery of the islands consists of non-granular tall columnar cells.

In granular cell ameloblastoma there is marked transformation of the cytoplasm, usually of stellate reticulum like cells, so that it takes a very coarse, granular eosinophilic appearance. Granular cell variety of ameloblastoma appears to be an aggressive lesion with a marked proclivity for recurrence. In addition, several cases of this type have been reported as metastasizing. The lesion have been shown to recur, particularly following inadequate surgical treatment [10].

A female patient aged 34 yrs complains of swelling of left side gingiva in the region of canine and premolar since 1 yr. Which was smaller in size and gradually grown to present size, with difficulty in chewing as the growth is interfering in occlusion. On examination the sessile growth originated from left side of gingiva both lingually and buccally in relation to premolars. Which was approximately of 3×4 cm in size and superiorly above the occlusal plane and inferiorly the buccal vestibule. The lesion extends anteriorly from canine and posteriorly till mesial aspect of first molar. It was non tender and no lymphadenopathy felt. After routine blood investigations the patient posted for excisional biopsy. Under general anesthesia peripheral osteotomy performed and specimen sent for histopathology diagnosis.

Histopathological report of excisional biopsy taken from right buccal vestibule in relation to 45 & 46 region revealed islands of ameloblastic epithelium in a fibrous connective tissue stroma. The centre of the island shows granular cells with eosinophilic granular cytoplasm and central nucleus. These features are suggestive of granular cell variant of ameloblastoma.

The granular cell ameloblastoma is characterized by the presence of large masses of granular cells located within the follicles (Figure 1). This occurs in 1% - 5% of cases [15,16]. The cells are large, round, or polyhedral, and densely packed with eosinophilic granules and frequently demonstrate well-defined borders but, in some instances, form a syncytium. The nuclei are generally pyknotic and eccentrically displaced (Figures 2 and 3). The cells replace all or part of the stellate reticulum and, quite often the peripheral cells as well [15,17]. The granular cells are periodic acid-Schiff-positive and diastase resistant [18]. In our case much similar histopathologic finding of granular cell variant seen clearly.

Figure 1:

Figure 2:

Figure 3:

They are considered to be of ectodermal origin [19] and are apparently derived from odontogenic epithelium [15], the most likely source being elements of the enamel organ [20-24], specifically ameloblasts [20,27]. The significance of the granular cells has been a matter of conjecture. Several investigators have considered them to represent a degenerative alteration [23,25-28], an aging phenomenon [28], or an attempt to form enamel matrix precursor [29]. However, ultra structural and histochemical studies have disclosed that the granules are actually lysosomes [18,19,26,27,30,31]. The granular cells are periodic acid-Schiff-positive, diastase resistant [18]. They are also positive for antichymotrypsin, antitrypsin, and keratins [18,31-34], as well as acid phosphatase and various oxidative enzymes [35], but are negative for vimentin [18,34], S-100 protein and neuron specific enolase [31,34].

The aggressiveness of this has been correlated with an enhanced DNA synthesis [36,37] and can also be attributed to the similarity of behavioral features between the ameloblastoma and the dental lamina. Both have the inherent ability to invade connective tissue and the columns of proliferating cells of the dental lamina are highly reminiscent of the invasive extensions seen with the ameloblastoma. Consistent with this aggressiveness is the presence of carcinoembryonic antigen (CEA) within more mature cells that demonstrate squamous differentiation or within cystic spaces formed by tumor islands composed of these cells.

The surgical management of ameloblastoma remains controversial issue in oral and maxillofacial surgery because of the unique biological behavior of this disease as a slow growing locally invasive tumor with high recurrence [38,39]. Treatment of ameloblastoma should be based on an accurate history, careful clinical examination, routine radiographs, special imaging, and representative biopsy reviewed with an oral pathologist. Surgical options include segmental resection, en bloc resection, simple curettage, and excision with peripheral ostectomy [40]. Because of its nature of tumor we have done aggressive treatment. At the time of presentation our case finished 5 yrs of follow-up without any recurrences. Further patient has been instructed to have follow-up visits for every year for another two follow-ups. Patient is now considered for prosthetic rehabilitation with help of removable partial denture. In near feature we are planning for rehabilitation of the patient using implant supported prosthesis.

The literature indicates the cystic variant is biologically less aggressive and has a better response to enucleation or curettage than does the solid ameloblastoma [3,6,38,40,41]. Unicystic lesions are often enucleated or curetted before the true diagnosis is known, and the surgeon may be reluctant to recommend a more aggressive approach depending on nature of these lesions. In six studies of cystic ameloblastoma, the overall recurrence rate for all cases was 15%. Reported recurrence rates of solid ameloblastomas treated by curettage range from 55% to 90% [10].

The location of the lesion, the extent of expansion, the presence of sound uninvolved cortical bone, and, to some degree the histologic nature of the tumor are all factors that must be considered when designing therapy [8]. Successful treatment is the one that renders an acceptable prognosis, causing minimal disfigurement and is based on the behavior and potential of the tumor. Because of the late recurrence of the lesion, long- term follow-up is indicated in all patients. So here we presented case of granular cell ameloblastoma with successful treatment of 5 yr follow-up without any recurrence.
